Large Fabrication and Industrial Machinery Measurement, Alignment, Leveling, and More

Optimize your unique large-volume jobs with modern laser tracker technology and Verisurf software. Do things with one operator that many have to do with two. Automate the whole process with extremely intuitive, graphical electronic work instructions (program plans) that are a must for working long distances from the device and the operator workstation.

Measurement-metrology for complex industrial application with laser trackers, photogrammetry, scanning and other metrology.

• Industrial machinery and fabrication equipment commissioning, setup, calibration, and checkout
• Large machine precision leveling, plumb, and complex measurement checks
• Precision roller alignment
• Robot setup, alignment, and calibration/mapping
• Metrology for robot adaptive control
• Precision parallelism, perpendicularity, concentrically, etc., for moving mechanisms

Shopfloor Automated Inspection

The Verisurf CMM Master is an optimized Renishaw^® Equator™ automated gauging system upgraded with Verisurf software and volumetric error compensation mapping. This creates a shopfloor CMM that maintains the efficiency of comparator mode but eliminates the extensive mastering process that requires baseline runs on a separate CMM.

CMM Programming

Productive for All Skill Levels

CMM programming right inside a full CAD/CAM system. Use the same software for your CMM paths that is used for CNC milling machine paths. This is not a rudimentary add-on, it is a high-powered, full-functioning CMM software that programs and operates all brands and types of CMMs, including 5-axis systems. Verisurf replaces many legacy OEM software packages that were designed “old-school” requiring lots of training and expertise to learn complex coding and text editing.

5-Axis CMM Efficiency

Increased Productivity for Automated CMMs

Take advantage of the productivity improvements that 5-axis CMMs have to offer. Verisurf adds unique path patterns, programming, and editing features to help users realize a rapid return on their 5-axis investment. Five-axis provides reduced setup time, fewer requirements for special fixturing, and less probe qualification time. Verisurf special features for 5-axis adds even more opportunities for process efficiency and control.

3D Scanning

Inspection & Reverse Engineering

Verisurf optimizes both the scanning process and post-processing workflows for both reverse engineering and inspection. Inspection includes automated workflows, automatic feature extraction, full model-based GD&T, and support for all scanning devices. Reverse engineering includes mesh creation, cleanup, filtering, optimization, registration/alignment, and full CAD-supported parametric modeling.

First Article & In-Process Inspection

Portable CMM Efficiency and Versatility

See how you can vastly improve your first article and in-process inspection jobs in less time and complexity.

The solution also requires considerably less training and experience from the system operators, while minimizing the pre-inspection preparation and setup time.
